SON28 & SONdelux SL & SL Disc


SONdelux SL

New for 2011, Wilfried Schmidt has made dynamo lighting more convenient and reliable than ever. Until now, you have had to manually disconnect wires from the hub dynamo before removing the wheel, and then reconnect those wires when reinstalling the wheel. Late at night on a 600k brevet or while riding home from work in the rain or snow, it can be a bit awkward to reconnect wires with cold fingers after fixing a flat tire.

The Schmidt SL hub axle eliminates the need to connect and disconnect wires when mounting and dismounting your dynamo wheel. Designed to be used with a specially made fork, the hub makes the electrical connection directly through the fork dropouts. Once you clamp the skewer tight, just get back on the bike and ride. Your lights will be working perfectly.

The right side axle end isolates the surface that faces the dropout from the axle center. The axle itself carries the ground side of the electrical circuit. The dropout face on the right side of the hub carries the power side of the circuit. You can easily tell the difference between the right and left side by looking at the axle end cap. The right side cap is wider than the left side cap. The right side cap must only be inserted in the fork on the right side of the bike. With the disc version of the hub, the disc is always on the left so there's never a chance of mounting the hub backwards. Also, the printing on the hub flange is only on the right side of the hub shell. In the dark, you can feel the printing on the right side of the hub, so you know which way to install your wheel.

At night without lights, if you mount the wheel backwards in the fork you get a short circuit and your lights will not work. Simply reverse the wheel and all is well, no harm done to either lights or hub. Even riding at high speed on long descents with the wheel backwards will caue no damage. There would only be increased drag due to shorting the output of the hub, but that drag would still be less than if you were using a sidewall dynamo. If you mount your disc wheel backwards, I offer remedial cycling courses on Wednesday nights. Bring your own cognac and witty repartee. :-)

The Schmidt SL hub won't work as a dynamo on standard forks. Your fork must be specially made. The inside surface of the right side dropout carries the power side of the circuit. Many older forks can be modified by a frame builder. If you're having a frame builder make you a new frame, have the builder contact us for details on building a fork that's compatible with the SL hub. An SL compatible fork can be used with any normal hub, whether it is a dynamo or not. But an SL hub cannot be used in a standard fork if you want to use its power output. See below for frame builders who are building SL forks.

SL hubs can be used with any 5mm skewer. Unlike other Schmidt hubs, the SL hubs do not come with a skewer.

SONdelux SL hubs are available red anodized, both Centerlock disc and without disc mounts. However, the SON28 SL is available red anodized only in the ISO (six bolt) disc version.

The red anodizing is done by the same company that does the red anodizing of Rohloff hubs, so these are a perfect color match with Rohloff, and of course they match the red Edelux headlight.


Prices - SONdelux SL Hubs

SONdelux SL Polished, 20 hole, Part Number SCH262005: $ 272.00
SONdelux SL Polished, 24 hole, Part Number SCH262405: $ 272.00
SONdelux SL Polished, 28 hole, Part Number SCH262805: $ 272.00
SONdelux SL Polished, 32 hole, Part Number SCH263205: $ 272.00
SONdelux SL Polished, 36 hole, Part Number SCH263605: $ 272.00

SONdelux SL Silver Anodized, 32 hole, Part Number SCH263295: $ 288.00
SONdelux SL Silver Anodized, 36 hole, Part Number SCH263695: $ 288.00

SONdelux SL Black Anodized, 20 hole, Part Number SCH262015: $ 288.00
SONdelux SL Black Anodized, 24 hole, Part Number SCH262415: $ 288.00
SONdelux SL Black Anodized, 28 hole, Part Number SCH242815: $ 288.00
SONdelux SL Black Anodized, 32 hole, Part Number SCH263215: $ 288.00
SONdelux SL Black Anodized, 36 hole, Part Number SCH263615: $ 288.00

SONdelux SL Red Anodized, 32 hole, Part Number SCH263225: $ 304.00

Prices - SONdelux SL Centerlock Disc Hubs

SONdelux SL Disc Polished, 32 hole, Part Number SCH273205: $ 320.00
SONdelux SL Disc Polished, 36 hole, Part Number SCH273605: $ 320.00

SONdelux SL Disc Black Anodized, 32 hole, Part Number SCH273215: $ 336.00
SONdelux SL Disc Black Anodized, 36 hole, Part Number SCH273615: $ 336.00

SONdelux SL Disc Red Anodized, 32 hole, Part Number SCH273225: $ 352.00

Prices - SONdelux Wide Body SL Hubs

SONdelux wide body SL Polished, 32 hole, Part Number SCH263207: $ 314.00
SONdelux wide body SL Polished, 36 hole, Part Number SCH263607: $ 314.00

Prices - SON28 SL Hubs

SON28 SL Polished, 32 hole, Part Number SCH303205: $ 272.00
SON28 SL Polished, 36 hole, Part Number SCH303605: $ 272.00

SON28 SL Silver Anodized, 32 hole, Part Number SCH303295: $ 288.00
SON28 SL Silver Anodized, 36 hole, Part Number SCH303695: $ 288.00

SON28 SL Black Anodized 32 hole, Part Number SCH303215: $ 288.00
SON28 SL Black Anodized 36 hole, Part Number SCH303615: $ 288.00

Prices - SON28 SL Centerlock Disc Hubs

SON28 SL Centerlock Disc Polished 32 hole, Part Number SCH323205: $ 320.00
SON28 SL Centerlock Disc Polished 36 hole, Part Number SCH323605: $ 320.00

SON28 SL Centerlock Disc Silver Anodized 32 hole, Part Number SCH323295: $ 336.00
SON28 SL Centerlock Disc Silver Anodized 36 hole, Part Number SCH323695: $ 336.00

SON28 SL Centerlock Disc Black Anodized 32 hole, Part Number SCH323215: $ 336.00
SON28 SL Centerlock Disc Black Anodized 36 hole, Part Number SCH323615: $ 336.00

Prices - SON28 SL ISO Disc Hubs

SON28 SL ISO Disc Polished 32 hole, Part Number SCH313205: $ 320.00
SON28 SL ISO Disc Polished 36 hole, Part Number SCH313605: $ 320.00

SON28 SL ISO Disc Silver Anodized 28 hole, Part Number SCH312895: $ 336.00
SON28 SL ISO Disc Silver Anodized 32 hole, Part Number SCH313295: $ 336.00
SON28 SL ISO Disc Silver Anodized 36 hole, Part Number SCH313695: $ 336.00

SON28 SL ISO Disc Black Anodized 28 hole, Part Number SCH312815: $ 336.00
SON28 SL ISO Disc Black Anodized 32 hole, Part Number SCH313215: $ 336.00
SON28 SL ISO Disc Black Anodized 36 hole, Part Number SCH313615: $ 336.00

SON28 SL ISO Disc Red Anodized 28 hole, Part Number SCH312825: $ 352.00
SON28 SL ISO Disc Red Anodized 32 hole, Part Number SCH313225: $ 352.00
SON28 SL ISO Disc Red Anodized 36 hole, Part Number SCH313625: $ 352.00

SON XS, SON 28 15 and SON 28 135 hubs are not available with the SL axle version.

All SL hubs ship without the 5mm allen skewer that the standard Schmidt hubs come with. Prices for the SL hubs are now a bit less than for the other Schmidt hubs due to the axle being a bit less expensive to make, and the lack of a skewer. Don't be confused though. These hubs have hollow axles and work with any 5mm front hub skewer.


Schmidt SL Forks, 26" 559, Disc or Canti

I stock forks from Schmidt with the necessary features. They are sized for 26" 559 wheels. One model has studs for cantilever brakes, and the other has disc brake mounts. Both forks are aluminum and painted black. They have a 1 1/8" threadless steerer, the most common type on modern bikes. If you use a different wheel size or use another type of brake, you will need to contact a frame builder and have a fork built to work with the Schmidt SL or SL Disc hub. I stock the necessary dropouts, connections and tools which will make it easy for any frame builder to build a suitable fork, as well as parts and tools to modify existing steel forks. Pictured below is the Schmidt fork for cantilever brakes.

fork

Notice the wire at the fork crown. That's the power side of the electrical circuit. The stainless steel washer at the crown is the base for the headlight's mounting bracket. You need to use a steel bracket that will conduct the ground side of the circuit to the base of the headlight. The Schmidt Edelux and E6 headlights conduct ground through their mounting base.

dropout

Here's a close-up photo of the right dropout. This is really the key to the whole system. There is a stainless steel plate on the inside surface of the dropout, and it is insulated from the rest of the fork. You can see the wire that carries the power side current to the headlight. It runs through the right fork blade. In the upper photo, you can see the wire at the fork crown.

The fork measures 383mm from the hub axle to the bottom of the crown, and 420mm from the hub axle to the crown race. It is suitable for frames designed to accommodate suspension forks.

Schmidt 26" (559) aluminum fork for SL hub, cantilever brake studs, mid fork rack eyelets, 1 1/8 threadless steerer, painted Black: $ 262.08 In Stock

Schmidt 26" (559) aluminum fork for SL Disc hub, disc brake mounts, mid fork rack eyelets, 1 1/8 threadless steerer, painted Black: $ 273.00 In Stock.


Custom Building a Fork?

If your bike uses side pull caliper brakes, or any wheel size other than the 26" 559, or you want a lugged steel fork, or anything other than the Schmidt 26" SL forks shown above, you'll need to have a fork built to use the SL or SL Disc hub. I stock several types of special dropouts your frame builder will need for a steel fork.

And you frame builders, keep in mind: The prices here are retail. I have wholesale pricing for professional frame builders.

Note!

Unless otherwise noted, these dropouts put the contact plate on the right dropout, so the wire will run up inside the right fork blade. We do have one version for left side contact plate and wiring. See below.


Stainless Steel - 11mm x 6mm tabs

45 Degree, Rear Facing, W/O Lips

dropouts

These have a slot at 45 degrees to the fork blade. And we have contact plates made with the electrical connection tab at 45 degrees as well. The right dropout is pictured here on the left. Use the 45 degree rear facing contact plate with these dropouts. Being stainless, there's no need for a stainless ground plate on the left dropout.

Stainless dropouts with 11mm tabs, 6mm thick. Part # SCHSLDR11, Retail Price: $ 50.32



Contact parts you'll need for these dropouts

SL Insulating Plate, Part # SCHSLIP, Retail Price: $ 14.00

SL 45 degree Contact Plate (presses into insulating plate) Part # SCH73122, Retail Price: $ 6.50

Or Choose

Set of contact parts for 45 degree (contact plate with wire soldered in place plus insulator plate. In other words, this is part # SCHSLIP and SCH73122 [Above] with soldered wire packaged together) Part # SCH73100,
Retail Price: $ 20.00


Mild Steel - 11mm x 4mm tabs

45 Degree, Rear Facing, W/O Lips

These mild steel dropouts are intended for the builder of traditional style forks. These forks have crowns that are narrower than the 100mm dropout spacing, so the blades aren't parallel, and the dropouts need to be at an angle to the blades. With 4mm thick tabs, these are much easier to align after brazing. You'll need to silver solder a stainless steel ground plate to the left dropout to ensure good conductivity.

Mild steel SL dropouts with 11mm x 4mm tabs. Part # SCH73709 Retail Price: $ 50.00

Contact parts you'll need for these dropouts

SL Insulating Plate, Part # SCHSLIP, Retail Price: $ 14.00

SL 45 degree Contact Plate (presses into insulating plate) Part # SCH73122, Retail Price: $ 6.50

Or Choose

Set of contact parts for 45 degree (contact plate with wire soldered in place plus insulator plate. In other words, this is part # SCHSLIP and SCH73122 [Above] with soldered wire packaged together) Part # SCH73100,
Retail Price: $ 20.00

And You'll Need

Stainless steel ground contact plate for left dropout, part #SCHSLGCP, Retail Price: $ 4.00


Mild Steel - 11mm x 4mm tabs

For Left Side!

45 Degree, Rear Facing, W/O Lips

For the builder who prefers to have the wire run up the left fork blade, which can make for a cleaner installation of the headlight on the left side of a custom front rack, since the wire from the contact plate doesn't need to run across the fork crown.

These are not for use on a fork with disc brakes!

These mild steel dropouts are intended for the builder of traditional style forks. These forks have crowns that are narrower than the 100mm dropout spacing, so the blades aren't parallel, and the dropouts need to be at an angle to the blades. With 4mm thick tabs, these are much easier to align after brazing. You'll need to silver solder a stainless steel ground plate to the right dropout to ensure good conductivity.

Mild steel SL dropouts with 11mm x 4mm tabs for left side contact plate. Part # SCH73710,
Retail Price: $ 50.00

Contact parts you'll need for these dropouts

SL Insulating Plate, Part # SCHSLIP, Retail Price: $ 14.00

SL 45 degree Reversed Contact Plate (presses into insulating plate in left dropout) Part # SCH73123,
Retail Price: $ 6.50

And You'll Need

Stainless steel ground contact plate for right dropout, part #SCHSLGCP, Retail Price: $ 4.00


Stainless - 11mm x 6mm tabs

45 Degree, Rear Facing, Lawyer Lips

dropouts

The right dropout is pictured on the left. On the right, you see the outside surface of the left dropout, showing the lawyer lips.

Schmidt 11mm x 6mm tabbed stainless dropouts with lawyer lips, 45 degree slot, rear facing.
Retail Price: $ 72.80

Contact parts you'll need for these dropouts

SL Insulating Plate, Part # SCHSLIP, Retail Price: $ 14.00

SL 45 degree Contact Plate (presses into insulating plate) Part # SCH73122, Retail Price: $ 6.50

Or Choose

Set of contact parts for 45 degree (contact plate with wire soldered in place plus insulator plate. In other words, this is part # SCHSLIP and SCH73122 [Above] with soldered wire packaged together) Part # SCH73100,
Retail Price: $ 20.00




Mild Steel - 11mm x 4mm tabs

45 Degree, Rear Facing, Lawyer Lips

Mild steel version tabs are 4mm wide making them easier to align in forks with traditional narrow crowns. You'll need to silver solder a stainless steel ground plate to the left dropout to ensure good conductivity.

Schmidt 11mm x 4mm tabbed mild steel dropouts with lawyer lips, 45 degree slot, rear facing. Retail Price: $ 72.80

Contact parts you'll need for these dropouts

SL Insulating Plate, Part # SCHSLIP, Retail Price: $ 14.00

SL 45 degree Contact Plate (presses into insulating plate) Part # SCH73122, Retail Price: $ 6.50

Or Choose

Set of contact parts for 45 degree (contact plate with wire soldered in place plus insulator plate. In other words, this is part # SCHSLIP and SCH73122 [Above] with soldered wire packaged together) Part # SCH73100,
Retail Price: $ 20.00

And You'll Need

Stainless steel ground contact plate for left dropout, part #SCHSLGCP, Retail Price: $ 4.00


Stainless - 16mm x 6mm tabs

45 Degree, Rear Facing, W/O Lips

dropouts

Stainless 45 degree rear facing dropout set with 16mm tabs. Part # SCHSLDR15: $ 50.32

Same as above but with lawyer lips. Not pictured, Part # SCH73704: $ 72.80

Contact parts you'll need for these dropouts

SL Insulating Plate, Part # SCHSLIP, Retail Price: $ 14.00

SL 45 degree Contact Plate (presses into insulating plate) Part # SCH73122, Retail Price: $ 6.50

Or Choose

Set of contact parts for 45 degree (contact plate with wire soldered in place plus insulator plate. In other words, this is part # SCHSLIP and SCH73122 [Above] with soldered wire packaged together) Part # SCH73100,
Retail Price: $ 20.00


Assembly

dropouts with connector

Here the right dropout is shown with the insulating plate and contact plate before they've been pressed together. That wouldn't be done until after the dropout is brazed or welded to the fork blade.

connector

Contact plate complete with wire attached and insulator plate. Retail Price: $ 23.50


Stainless, Socketed, 30 Degrees

dropouts

These socketed stainless steel dropouts have a 30 degree slot. This is the same shape as in the Schmidt SL fork. They fit a fork blade with 17mm ID. Use with the 30 degree rear facing contact plate.

Schmidt Stainless dropouts with lawyer lips for 17mm ID fork blades, Part # SCH73720: $ 72.80

Schmidt 30 degree contact plate, rear facing slot, Part # SCHSLCP: $ 6.50

SL Insulating Plate, Part # SCHSLIP, Retail Price: $ 14.00


Forward Facing Dropouts

dropouts

We now have forward facing dropouts from Tout Terrain. These are the same dropouts Tout Terrain uses on their "Blade" forks. They use the same insulator as the Schmidt dropout shown on the right, but then use a reversed contact plate.

Tout Terrain SL dropouts, Part # TOU-R-DO-FO-DK : $ 50.00

Schmidt forward facing contact plate 30 degrees, for Tout Terrain dropout, Part # SCH73121: $ 6.50

SL Insulating Plate, Part # SCHSLIP, Retail Price: $ 14.00


Stainless 11mm x 6mm

Zero Degrees

dropouts

Schmidt stainless dropouts with straight slots and 11mm tabs, no lawyer lips, Part # SCH73707: $ 50.00


Stainless with Plugs, Zero Degrees

dropouts

From left to right, 13.6mm, 11.5mm, and 10.7mm. For each pair, the left dropout shows the retaining ring (lawyer lips) and the right shows the holes for inserting the insulator plate and contact plate. The builder could grind off the retaining ring if desired.

Schmidt Stainless 10.7mm plug type straight, Part # SCH73730: $ 84.00

Schmidt Stainless 11.5mm plug type straight, Part # SCH73731: $ 84.00

Schmidt Stainless 13.6mm plug type straight, Part # SCH73732: $ 84.00


Straight Contact Plate

Schmidt contact plate for straight dropouts, Part # SCH73124: $6.50

SL Insulating Plate, Part # SCHSLIP, Retail Price: $ 14.00

Or Choose

Set of Straight Contact Parts

dropouts

Here is the set of contact parts for the straight dropouts. After brazing the dropouts, painting the fork and routing the wire, just press in the parts and you're done.

Schmidt set of contact parts (contact plate, soldered wire, insulator) for straight dropouts,
Part # SCH73102: $ 20.00


Contact Plates

contact plates

From left to right, all of the available (February, 2013) contact plates: forward facing 45 degree, forward facing 30 degree, straight, rear facing 30 degree, and rear facing 45 degree.

Notice that there's a forward facing 45 degree contact plate, but no forward facing 45 degree SL dropouts. We make this for custom builders who want the contact plate on the left dropout. Shimano road dropouts have a 45 degree slot and I'm guessing others are similar. So if you use the Solder Plate (seen below) to create a left side SL dropout based on a typical road dropout, the 45 degree forward facing contact plate will work as a rear facing left side contact plate.


Contact Plate Press

tool

The tool for pressing the contact plate, insulating plate and dropout together. The left side of the tool fits between the two dropouts in the finished fork. The right side tightens the right dropout assembly together.

Dropout Press. Retail Price: $ 40.00
